Air Quality Monitor Elitech Temtop M2000

• Buzzer status.
• Display the two states of the detector.
• Date and time.
• The battery is empty, please charge. i: Battery is full. i: Charging.
• Main display area.
• Menu button.
• Up button.
• Return button.
• Power on/off or confirm.
• Down or run/pause button.

The functions of the above menu items are as follows:

• • Pause or start measuring”: The detector pauses or continues measuring CO, concentration and its level.
  • Tum on or off the alarm sound”: When the detected concentration is higher than the pre-set value, the buzzer will beep. Select this option to mute the beep.
  • Display or not display the curve”: Select this option to display the curve of measured data visually. If you choose “Not display the curve”, the curve will be shifted to data.
  • “Alarm value setting ” Press.A or .to select this option and then press%to enter the interface. Press A or. to adjust the upper-limit alarm value of CO, and concentration. Press == to shift. After switching to “Save” or” Exit”, press %- to confirm the settings and back to the interface of settings.
  • Calibration zero”: It pops up a window showing “Calibrating sensor”. Please place the detector outdoors for 30 minutes until the Zero point calibration of the CO2 sensor is finished. Press 1Jor%-to exit.
  • Exit”: Exit the menu options and then return to the interface of CO2 concentration.

Technical Specifications:

• Name: Hand-Held Air Quality Detector
• Model: M2000
• Display: color TFT LCD screen
• Battery voltage: 3. 7VDC
• Overall dimension: 73.5 x 139 x 37.5 mm
• Power adapter: Output voltage: 5VDC Output current: 1A
• Operating environment:
• Temperature range: 0-50
• Humidity range: 0-90%RH Atmospheric pressure: 1 aim
• PM2.5 technical specification 3 Measurement range: 0-999ug/m 3Resolution: 0.1 ug/m
• PM10 technical specification Measurement range: 0-999ug/m

Air Quality Parameter for Reference
