Key Features:
-
Setting menu:
Long press the M key product into the setting interface, at this time short press the mode key to switch the menu items, short press the right key to switch the setting options. The product menu items include: vacuum unit, temperature unit, recording interval, automatic shutdown time, backlight time, display language, about.
-
leak test:
Short press the M key to enter the leakage test interface, the temperature display area shows the target value, decay value and test duration of the leakage test. When the current vacuum value is lower than the target value, you can choose to turn on or cancel the leakage test according to the prompts in the interface, and you can also manually turn on or stop the
- 1. Long press the power button to turn on the product.
- 2. Long press the M button to enter the setting, by pressing the M button to select the item that needs to be modified, press the right button to select the setting content of the item.
- 3. Long press M key to exit or wait for the product to exit automatically.
- 4. Interface down to install the vacuum gauge, measure the vacuum can be. leakage test by short pressing the right key. After the leakage test ends automatically, the product displays the test report, and press the right button to return to the test interface. If the right button is pressed during the leakage test, the test will be exited manually and the test report will no longer appear.
Technical Specifications:
- Measuring range: 1-760000 microns;
- Resolution: 1-500microns 1 microns.
500-2000microns 5 microns.
2000-5000microns 50 microns.
5000-25000microns 250 microns.
25000-760000microns 500 microns. - Accuracy: ±10% of reading ±10microns (at 25℃);
- Power supply: 3 AA batterie;
- Time in use: 120H;
- Units: inHg,Torr,psia,mbar,mTorr,Pa,micron,kPa;
- Operating temperature: 0°F～140°F (-17.8°C ～60°C);
- Wireless transmission distance: 100m ;
- Offline Records: 10000 readings;
- Fitting: 1/4” SAE male flare;
- Product size: 127*74*37mm;
- Max overpressure: 27.5 bar;
Operation:
- Long press the power button to turn on the product.
- Long press the M button to enter the setting, by pressing the M button to select the item that needs to be modified, press the right button to select the setting content of the item.
- Long press M key to exit or wait for the product to exit automatically.
- Interface down to install the vacuum gauge, measure the vacuum can be.
